Y3224, Spur Gear

Y3224

Y3224

Y3224, Spur Gear, Brass

Learn more about Y3224 Spur Gears and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number Y3224
Teeth 24
Type 6
Material Brass
Bore Type Minimum Plain Bore
Bore (in) 0.188
Bore Description 3/16 Inch Minimum Plain Bore
Pitch Diameter (in) 0.750
Outside Diameter (in) 0.812
Face Width (in) 0.188
Overall Length (in) 0.438
Hub Diameter (in) 0.530
Unit System Inch
MOQ 1
Weight (lb) 0.04
Part Number Cross Reference A 1B 1-Y32024, Y3224, Y3224
Pressure Angle 20.0
Diametral Pitch 32

Comparable to: A 1B 1-Y32024, Y3224, Y3224
