84T48P20-6P3, Gear

84T48P20-6P3

84T48P20-6P3

84T48P20-6P3, Gear, Plastic

B&B Manufacturing carries 84T48P20-6P3 to accommodate the different industries we serve. Contact us today for a free quote!

Specifications

Product Number	84T48P20-6P3
Teeth	84
Tooth Style	48
Material	Acetal
Bore (in)	0.250
Bore Description	1/4 Inch Bore
Pitch Diameter (in)	1.750
Outside Diameter (in)	1.792
Face Width (in)	0.125
Overall Length (in)	0.375
Hub Diameter (in)	0.609
Unit System	Inch
MOQ	1
Weight (lb)	0.02
Part Number Cross Reference	A 1M 2-Y48084, 84T48P20-6P3, 84T48P20-6P3
Pressure Angle	20.0
Diametral Pitch	48

Related Products

Comparable to: A 1M 2-Y48084, 84T48P20-6P3, 84T48P20-6P3
